Product Category
Range: 0-0.6MPa to 4MPa
Pressure type: gauge pressure
Overload capacity: allows overload up to 5 times the sensor range
Destroy pressure twice the sensor range
Comprehensive accuracy: 5% F.S
Long term stability: 5% F.S/year
Working temperature: 0 ℃~50 ℃
Power supply: 18V~30VDC (recommended 24VDC power supply)
Output signal: 4mA~20mADC
Protection level: IP65
Warranty period: twelve months
